The single-screw, Diesel-engine motor ship with raking stem and bulbous bow, transom stern and flap-rudder. The hull is fully welded. Main deck to be continuous in full length. Double bottom extends from forepeak compartment to E.R. bulkhead. In way of E.R., a double bottom with increased height will be arranged. The vessel to be provided with forecastle, poop and aft deckhouse.

Year Built:

2006

Place Built:

Peoples Republic of China

Capacity

1105 TEU

Flag:

Cyprus

Call sign:

C4JA2

Classification Society

Russian Maritime Register of Shipping

Class notation:

KM* Ice1 AUT1

Specification

Technical specification

  • Characteristics

    Length o.a.:

    147.87 m

    Length between perpendiculars:

    140.30 m

    Breadth:

    23.25 m

    Depth:

    11.50 m

    Draft summer load line:

    8.50 m

    Deadweight:

    13806,2 t

    Register tonnage gross:

    9957

    Register tonnage net:

    5032

    Service speed laden:

    17.7 kn

    Capacity TEU:

    1105 (Hold - 334, Hatches + Main Deck - 771)

    The number of stability containers (14t) TEU:

    700

    TEU + FEU (40'):

    31 + 537 (FEU: Hold - 162, Hatches+Main Deck - 375)

    Reefer sockets:

    220

    Cargo Cranes

    2 × 40/45 t, electro-hydraulic (boom 26.5/29,5 m)

  • Permissible load

    Tank Top:

    TEU-120t, FEU-150t, 12t/m2

    Hatches:

    TEU-50t, FEU-80t, 1,75t/m2

    Main Deck:

    TEU-65t, FEU-80t

  • Fuel consumption

    HFO

    MDO

    Recommended

    RMG 380

    DMA

    Viscosity, cSt

    380,0

    6,0

    At sea, mt/day

    RMG 380 - 37,2 mt/day

    In port (working), mt/day

    RMG380 – 3,9 mt/day

    In port (idle), mt/day

    RMG380 – 2,0 mt/day

    For maneuvers, kg/hrs

    RMG380 – 554 kg/hrs

    In the case of carriage working ref. containers, the additional fuel consumption 37 kg/day provides on each container.

    SHIP'S STORE (BUNKER)

    TON

    HFO

    1361,32

    MDO

    226,10

    Water ballast

    5196

  • Cargo spaces

    HOLD, SIZE L × B × H

    HATCH, SIZE L × B

    1

    14,7 × 5,0/10,4 × 7,1/9,9

    14,0 × 10,4

    2

    12,6 × 7,5/18,0 × 9,9

    12,6 × 18,0

    3A

    12,6 × 12,5-18,0/18,0 × 9,9

    12,6 × 18,0

    3B

    14,7 × 18,0 × 9,9 12,6 × 18,0

    12,6 × 18,0

    4A

    14,7 × 18,0 × 9,9 12,6 × 18,0

    12,6 × 18,0

    4B

    12,6 × 18,0 × 9,9 12,6 × 18,0

    12,6 × 18,0

    5

    12,6 × 12,5-7,5/18,0 × 9,9

    12,6 × 18,0
